Specification
| Category | Specification | |
| Working Wavelength | nm | 1260～1650 |
| Test Wavelength | nm | 1310&1490&1550 |
| Iisertion Loss | dB | ≤7.4 |
| Channel Uniformity | dB | ≤0.6 |
| Polarization Dependent Loss-PDL | dB | ≤0.2 |
| Directivity | dB | ≥55 |
| Return Loss | dB | ≥50（UPC）≥55（APC） |
| Repeatability | dB | ≤0.1 |
| Interchangeability | dB | ≤0.2 |
| Operating Temperature | ℃ | -40～+85 |
Product Features
-
- The ceramic process inserting core and conversion of suitable channels are very flexible.
-
- High quality transmission chipset with even light distribution and stronger light transmittance.
-
- Good stability, low polarization - dependent loss, low back reflection, compact structure.
Packge Method
Place the product in a small carton and then in a large carton to ensure the safety and beauty of the product.
