ABS Material Fiber Optic PLC Splitter 1X8 SCUPC Cassette Type Grey For WDM - PON
Planar Lightwave Circuit Splitter (PLC Splitter) is based on planar waveguide optical power distribution products, with low insertion loss and polarization-dependent loss, small size, wide operating wavelength range, high channel uniformity, and good characteristics, generally used in passive optical networks (EPON, BPON, GPON, etc.) to realize the optical power splitting. Our PLC splitters are compliant with Telcordia GR-1209-CORE, Telcordia GR-1221-CORE, YD/T 1117-2001, and RoHS standards.
ABS Material Fiber Optic PLC Splitter 1X8 SCUPC Cassette Type Grey For WDM - PON Features:
- 1xN and 2xN splitters tailored per application
- Low Insertion Loss and low PDL
- Superior Uniformity
- Wide Operation Wavelength
- Wide Operation Temperature
- High Stability and Reliability
ABS Material Fiber Optic PLC Splitter 1X8 SCUPC Cassette Type Grey For WDM - PON Applications :
- FTTX Networks
- PON Networks
- CATV Links
- Data Communication
- Optical Cable Cross Connection Cabinet
- Optical Fiber Distribution Box/Cabinet
ABS Material Fiber Optic PLC Splitter 1X8 SCUPC Cassette Type Grey For WDM - PON Design Type:
- 1x2, 1x4, 1x8, 1x16, 1x32, 1x64 splits
- 2x2, 2x4, 2x8, 2x16, 2x32, 2x64 splits
- Type: Bare-fiber type, micro type, ABS box type, Cassette type
- Adapter type of splitter: SC/UPC, SC/APC
2x8 PLC Splitter Cassette Type with LC UPC Adapter Specifications:
1. The Connector
| Project | Spec. | Standard |
| Operating wavelength | 1260～1650nm | GR-326-CORE；
IEC 61300 |
| Insertion loss | ≤0.3dB（Typical value：0.2dB) | |
| Return loss | ≥60dB（APC）≥50dB(UPC) | |
| Repeatability | ≤0.2dB | |
| Interchangeability | ≤0.2dB | |
| Mechanical Endurance | ≥500 Times | |
| Working temperature | -40～+85℃ |
2. Composition Information
| Category | Specification | Remarks | |
| PLC Splitter | Fiber Type | G657A1 | |
| Splitter Type. | 0.9mm-Mini Type | ||
| Product length | 0.4M | ||
| Connector Type | SC、FC or LC | ||
| The Box | Size | 130*100*25mm | |
| Material | ABS | ||
| Color | Grayish White | ||
| Channel marking | Yes | ||
