Specification

Fiber Count Tubes * fibers Filler number Outer Diameter Weight Minimum bend radius Tensile strength Crush resistance
Dynamic Static Short term Long term Short term Long term
mm kg/km mm mm N N N/100mm N/100mm
6 1x6 5 10.9x18.8 180 220 110 5000 2500 1000 300
12 2x6 4 10.9x18.8 180 220 110 5000 2500 1000 300
24 4x6 2 10.9x18.8 180 220 110 5000 2500 1000 300
36 6x6 0 10.9x18.8 180 220 110 5000 2500 1000 300
48 4x12 2 11.7x19.6 200 240 120 5000 2500 1000 300
60 5x12 1 11.7x19.6 200 240 120 5000 2500 1000 300
72 6x12 0 11.7x19.6 200 240 120 5000 2500 1000 300
96 8x12 0 13.1*21 230 270 135 5000 2500 1000 300
144 12x12 0 15.8x23.7 310 320 160 5000 2500 1000 300
192 8x24 0 14.9x22.8 280 300 150 5000 2500 1000 300
288 12x24 0 18.4x26.3 390 370 185 5000 2500 1000 300

Features

Excellent mechanical and temperature performance
Special tube filling oil ensures water-proof performance
Loose tube stranding cable core ensures the cable structure stable
Optional aluminum or corrugated steel sheathing

Application

Long distance, LAN communication
CATV &computer network system
Junction communication system

Installation

Self-supporting aerial

Packge Method

Multiple packaging options are available
